Liquid column manometers-Vertical-Model TX Series

AWS.10 liquid, density = 0.87

Applications : measuring overpressures and depressions in clean rooms, operating blocks, laboratories, aseptic rooms, laminar flows... Measurement range : 2,5-0-2,5 • 5-0-5 • 7,5-0-7,5 mmCE.

• Scale with centered zero.
• Possibility for measuring positive and negative pressures.
• High measurement sensitivity.
• Very low pressure ranges.
• Zero adjusting by moving the slide strip.
• Integrated spirit level for adjusting horizontality.
• Comes with a white PVC support, 2 screws and 2 rawlplugs, two 487 connectors and a bottle of AWS 10 liquid.

Accessories

Tubes

Clear and silicone tube

Clear tube Ø 5 x 8
For permanent installation (m/l or 25m).
Silicone tube Ø 4 x 7
Black or white, for test instruments (m/l or 25 m).

Connections accessories

Straight connection for Ø 5 x 8 tube.
T-connection for Ø 5 x 8 tube.
Y-connection for Ø 5 x 8 tube.

Manometers connections

Simple connection in chromed brass or Delrin, chromed brass safety, valve connection in chromed brassed (male/female 1/8 gas or female/male 1/8 gas)...

------------------------------------------------------------------------------------------------------------------------------------
